Light Blocking Effect Tester M112

This test method measures the light blocking properties of textile and related materials using a photometer.This method is applicable to all types of fabrics, including coated Textiles and other textile-based constructions.
  • Item No.:

    M112
  • Payment:

    TT, L/C, Wester Union
  • Product origin:

    MADE IN CHINA
  • Shipping port:

    Any Port of China
  • Lead Time:

    15-20 Days
  • Brand:

    UTSTESTER
  • Certificates:

    CE, ISO 17025 Calibration Certificate
  • Standards:

    AATCC 148

New Products

Call Us Now

+86 15260605085

  • Product details

M112 Light Blocking Effect Tester


Overview

M112 Light Blocking Effect Tester, it is used to measure the total visible light transmittance of fabrics to evaluate the shading performance of fabrics. It is suitable for sheet textile products such as curtain materials.
The instrument has unique design, compact structure, complete functions and convenient operation. The instrument is controlled by a single chip microprocessor and displayed with a color touch screen, which can realize full touch screen operation.


Standards

AATCC 148-2015



Key Specifications

Model

M112

Test illumination

about 7,000 lux

Sensor measurement range

0-200K LUX

Sensor measurement accuracy

±2%

Light source parameters

AC12V 5W LED lamp cup

Color temperature of light source

6000-6500K white light

Bulb life

about 15,000 hours

Power source

AC 220V±10% 50Hz 200W

Overall dimensions

765×410×504mm

Weight

30kg



Test Principle

It is used to measure the luminous illumination of the fabric when the light passes through the sample under a certain strong light irradiation, and the shading rate is calculated by comparing it with the illuminance without the sample.



Features

Touch screen control, man-machine dialogue mode, easy operation.
Built-in thermal printer for quick on-site printing of test results.
Report Statistics.
High precision sensor, good linearity, strong stability.



Material to be Tested

M112 Light Blocking Effect Tester is applicable for all types of fabrics, including coated Textiles and other textile-based constructions.
